18
Overview of Components
Important
Always unplug the power cord from the power outlet before installing or removing


with Return Merchandise Authorization (RMA) requests if only the motherboard comes


is necessary to prevent overheating and maintain system stability.

your system.



enhance heat dissipation.

the socket with the plastic cap.

documentation in the heatsink/ cooler package for more details about installation.
This motherboard is designed to support overclocking. Before attempting to
overclock, please make sure that all other system components can tolerate
overclocking. Any attempt to operate beyond product specifications is not
recommended. MSI® does not guarantee the damages or risks caused by inadequate
operation beyond product specifications.
CPU Socket
Introduction to the LGA 1200 CPU

two notches and a golden triangle to

motherboard placement. The golden
triangle is the Pin 1 indicator.
50.77 mm
Distance from the center of the
CPU to the nearest DIMM slot.
