Slots
PCIE (Perpheral Component Interconnect Express) Slot
The PCIE slot supports the PCIE nterface expanson card.
PCIE x16 Slot
PCIE x1 Slot
Important
When addng or removng expanson cards, make sure that you unplug the power sup-
ply 󰘰rst. Read the documentaton for the expanson card to con󰘰gure any necessary
hardware or software settngs, such as jumpers, swtches or BIOS con󰘰guraton.
