MSI H67MA-E45 series - LED Status IndCators

2-20
Hardware Setup
MS-7678
Chapter 2
LED Status Indcators
APS LED
The APS (Actve Phase Swtchng) LED ndcate the current CPU power phase mode.
Follow the nstructons below to read.
: Lghts : O󰘯
CPU s n 1 phase power mode.
CPU s n 2 phase power mode.
CPU s n 3 phase power mode.
CPU s n 4 phase power mode.
APS LEDs
