MS-7327 Mainboard
USB Connectors
The OHCI (Open Host Controller Interface) Universal Serial Bus root is for attaching
USB devices such as keyboard, mouse, or other USB-compatible devices.
Audio Port Connectors
These audio connectors are used for audio devices. You can differentiate the color
of the audio jacks for different audio sound effects.
Blue audio jack - Line In, is used for external CD player, tapeplayer or
other audio devices.
Green audio jack - Line Out, is a connector for speakers or headphones.
Pink audio jack - Mic In, is a connector for microphones.
Black audio jack - Rear-Surround Out in 4 / 5.1 / 7.1 channel mode.
Orange audio jack - Center/ Subwoofer Out in 5.1 / 7.1 channel mode.
Gray audio jack - Side-Surround Out in 7.1 channel mode.
