MS-7327 Mainboard
A-20
n 4-Channel Mode for 4-Speaker Output
Back Panel
Description:
Connect two speakers to back
panel’s Line Out connector and
two speakers to the real-chan-
nel Line Out connector.
4-Channel Analog Audio Output
1 Line In
2 Line Out (Front channels)
3 MIC
4 Line Out (Rear channels)
5 Line Out (Center and Subwoofer channel, but no functioning in this mode)
6 Line Out (Side Surround channels, but no functioning in this mode)
3
1
2
6
4
5
