Device Selection
options. The check sign indicates the devices as default.
guidance of anticipated sound effect for both output and input device.
Main Volume
that you plugged in front or rear panel by adjust the bar.
Jack Status
computer.
When you plug into a device at an audio jack, a dialogue window will pop up asking you
which device is current connected.
Each jack corresponds to its default setting as shown on the next page.
Important
The pictures above for reference only and may vary from the product you purchased.
After Realtek Audio Console is installed. You can use it to change sound settings to get
better sound experience.
Jack Status
Connector Settings
Device
Selection
Main Volume
Application Enhancement
