37


Hexadecimal 0 1 2 3 4 5 6 7 8 9 A B C D E F
Debug Code
LED display
0 1 2 3 4 5 6 7 8 9 A B C D E F
Boot Phases

 – memory initialization
 – main hardware initialization

bootable device (CD/DVD, HDD, USB, Network, Shell, …)


01 Power on. Reset type detection (soft/hard)
02 AP initialization before microcode loading
03 System Agent initialization before microcode loading
04 PCH initialization before microcode loading
06 Microcode loading
07 AP initialization after microcode loading
08 System Agent initialization after microcode loading
09 PCH initialization after microcode loading
0B Cache initialization

 Reserved for future AMI SEC error codes
0E Microcode not found
0F Microcode not loaded

10 PEI Core is started
11 
12 - 14 
15 
16 - 18 
19 
 
2B Memory initialization. Serial Presence Detect (SPD) data reading
 Memory initialization. Memory presence detection
2D Memory initialization. Programming memory timing information

Table of Contents

Other manuals for MSI MEG B550 UNIFY

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI MEG B550 UNIFY and is the answer not in the manual?

MSI MEG B550 UNIFY Specifications

General IconGeneral
Processor socketSocket AM4
Processor manufacturerAMD
Compatible processor seriesAMD Ryzen 3, AMD Ryzen 5, AMD Ryzen 7, AMD Ryzen 9 3rd Gen
Maximum number of SMP processors1
ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots4
Supported memory typesDDR4-SDRAM
Maximum internal memory128 GB
Supported memory clock speeds1866, 2133, 2400, 2667, 2800, 2933, 3000, 3066, 3200, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4533, 4600, 4733, 4866, 5000, 5100, 5600 MHz
RAID levels0, 1, 10
Supported storage drive typesHDD & SSD
Number of storage drives supported10
Supported storage drive interfacesM.2, SATA
DirectX version12.0
Maximum resolution4096 x 2160 pixels
Maximum graphics card memory16384 MB
Parallel processing technology support2-Way CrossFireX
USB 2.0 connectors2
Number of SATA II connectors0
Number of SATA III connectors6
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity3
LAN controllerRealtek RTL8125B
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax)
Bluetooth version5.1
Top Wi-Fi standardWi-Fi 6 (802.11ax)
WLAN controller modelIntel Wi-Fi 6 AX200
Ethernet interface type2.5 Gigabit Ethernet
Audio chipRealtek ALC1220P
Component forPC
Motherboard chipsetAMD B550
PC health monitoringFAN, Temperature
Audio output channels7.1 channels
Motherboard form factorATX
BIOS typeUEFI AMI
Cables includedSATA
Harmonized System (HS) code84733020
Weight1000 g
Weight and Dimensions IconWeight and Dimensions
Depth244 mm
Width304 mm
Height65 mm
