40
D9 Error loading Boot Option (LoadImage returned error)
Boot Option is failed (StartImage returned error)
DB Flash update is failed
Reset protocol is not available
E0 S3 Resume is stared (S3 Resume PPI is called by the DXE IPL)
E1 S3 Boot Script execution
E2 Video repost
E3 OS S3 wake vector call
E4 - E7 Reserved for future AMI progress codes
E8 S3 Resume Failed
E9 S3 Resume PPI not Found
S3 Resume Boot Script Error
EB S3 OS Wake Error
Reserved for future AMI error codes
F0 Recovery condition triggered by firmware (Auto recovery)
F1 Recovery condition triggered by user (Forced recovery)
F2 Recovery process started
F3 Recovery firmware image is found
F4 Recovery firmware image is loaded
F5 - F7 Reserved for future AMI progress codes
F8 Recovery PPI is not available
F9 Recovery capsule is not found
Invalid recovery capsule
FB - FF Reserved for future AMI error codes
