Chapter 1
1-2
CPU
z Supports Intel
®
Socket 370 Pentium III, Celeron-Tualatin, VIA C3, and Samuel2
processors.
z Supports up to 1.1GHz CPU.
Chipset
z Intel
®
810/810E (GMCH) chipset. (421 BGA)
- Integrated Graphics Controller.
- Intel DDM Architecture.
- SDRAM Memory Independent of System Bus.
z Intel
®
ICH chipset. (241 BGA)
- AC’97 Controller Integrated.
- 2 full IDE channels, up to ATA66.
- Low Pin Count interface for SIO.
Front Side Bus (FSB)
z 66/100/133MHz clocks are supported.
Main Memory
z Support two 168-pin DIMM sockets.
z Support a maximum memory size of 256MB(64-bit) or 512MB(128-bit)
SDRAM.
Slots
z One AMR (Audio Modem Riser) slot.
z Three PCI 2.2 32-bit PCI bus slots (support 3.3v/5v PCI bus interface)
z One 16-bit ISA bus slot (optional).
On-Board IDE
z An IDE controller on the ICH chipset provides IDE HDD/CD-ROM with
PIO, Bus Master and Ultra DMA66 operation modes.
z Can connect up to four IDE devices.
On-Board Peripherals
z On-Board Peripherals include:
- 1 floppy port supports 2 FDDs with 360K, 720K, 1.2M, 1.44M and
2.88Mbytes.
- 2 serial ports (COM A + COM B).
Mainboard Specification
