Chapter 2
2-20
IrDA Infrared Module Header: IR or IR2 (optional Intel spec)
These connectors allow you to connect to IrDA Infrared modules. You
must configure the setting through the BIOS setup to use the IR function. The
difference between IR & IR2 is that IR2 is compliant to Intel Front Panel I/O
Connectivity Design Guide.
1
2
56
IR2
1 VCC
2NC
3 IRRX
4 GND
5 IRTX
Pin Signal
IR Pin Definition
1NC
2NC
3 VCC
4 GND
5 IRTX
6 IRRX
Pin Signal
IR2 Pin Definition
IR
1
