MSI MS-6378 - Wake on Ring Connector: JMDM1; Wake on LAN Connector: JWOL1

Chapter 2
2-20
Wake On Ring Connector: JMDM1
This connector allows you to connect to a modem card with Wake On
Ring function. The connector will power up the system when a signal is
received through the modem card.
Wake On LAN Connector: JWOL1
This connector allows you to connect to a LAN card with Wake On LAN
function. You can wake up the computer via remote control through a local
area network.
JMDM1
NC
WOR (wake-up on ring)
5VSB
1
GND
NC
JWOL1
GND
5VSB
WOL (wake-up on LAN)
1
