MSI MS-98F3 - Layout

1-4
Overview MS-98F3
Layout
Front Audio
Connector
Mini-PCIe/
mSATA Slot
Clear CMOS
Jumper
AT/ATX Jumper
SO-DIMM Slot
COM Port
Connector
USB 2.0
Connector
LVDS Inverter
Connector
SATA 3.0
Connector
GPIO Connector
System Fan
Connector
LVDS
Connector
COM Port
Power Jumper
LPC Debug
Port Connector
Front Panel
Connector
SATA Power
Connector
Amplier
Connector
LVDS Power
Jumper
Keyboard/Mouse
Connector
M.2 Slot
LVDS Inverter
Jumper
LAN2 Jumper
SMBus Connector
DC-In 12V/19V/24V
Power Connector
COM Port
Power Jumper
Back Panel
Intel ME
Jumper
