MSI MS-98F3 - LVDS Power Jumper: JVDD1; LVDS Inverter Power Jumper: JINV1; Intel ME Jumper: JME1

2-13
Hardware Setup MS-98F3
LVDS Power Jumper: JVDD1
Use this jumper to specify the operation voltage of the LVDS interface at panel.
1 1
3V 5V
LVDS Inverter Power Jumper: JINV1
Use this jumper to specify the operation voltage of the interver interface at panel.
+5V +12V
11
Intel ME Jumper: JME1
This jumper is used to enable/disable the Intel ME function.
ME enable ME disable
