Overview MS-S0121
1-3
Overview MS-S0121
Slot
1 PCI-Express x16 slot
1 PCI-Express x8 slot (2 PCI-Express x8 slots for C204 SKU)
2 PCI-Express x4 slots
1 32-bit/33MHz PCI slot
■
■
■
■
Form Factor
ATX form factor: 12” x 9.6”■
Mounting
10 mounting holes■
SKU Comparison
SKUs
Features
C202 SKU C204 SKU C204 SKU
AST2150 (with IPMI) V
AST2150 (with VGA) V V
SATA 6 Gb/s 0 2 2
SATA 3 Gb/s 6 4 4
PC1_E1 PCIE x16 slot
(x8 signal)
V V V
PCI_E2 PCIE x8 slot
(x8 signal)
V V V
PCI_E3 PCIE x8 slot
(x4 signal)
V V
PCI_E4 PCIE x4 slot
(x4 signal)
V V V
PCI_E5 PCIE x4 slot
(x1 signal)
V V V
JLAN1 GbE LAN
shared for Mgmt
V
