MS-7360 Mainboard
1-2
Processor Support
- Intel
®
Core 2 Extreme, Core 2 Quad, Core 2 Duo, Pentium and
Celeron in the LGA775 package
(For the latest information about CPU, please visit http://www.msi.
com.tw/cpusupport.htm)
Supported FSB
- 1333/ 1066/ 800 MHz
Chipset
- North Bridge: Intel
®
P35/ G33 (optional)
- South Bridge: Intel
®
ICH9/ ICH9R (optional)
Memory Support
- DDR2 667/800 SDRAM (240pin/ non-ECC)
- 4 DDR2 DIMMs (8GB Max)
(For more information on compatible components, please visit http:/
/www.msi.com.tw/testreport.htm)
LAN
- Supports Giga LAN 10/100/1000 Fast Ethernet by Realtek
RTL8111B
IEEE 1394(optional)
- Chip integrated by VIA VT6308
- Transfer rate is up to 400Mbps
Audio
- Controlled by Realtek ALC888
- Supports 7.1 channels audio out
- Compliant with Azalia Spec
IDE
- 1 IDE port controlled by Marvell 88SE6111
- Supports Ultra DMA 66/100/133, PIO & Bus Master operation
mode
SATA
- 4 SATA ports (SATA1~4) are controlled by ICH9
- 6 SATA ports (SATA1~6) are controlled by ICH9R
- SATA 7 is controlled by Marvell 88SE6111 (optional)
- Supports storage and data transfers at up to 300 MB/s
RAID
- SATA1~6 support RAID 0/ 1/ 0+1/ 5 or JBOD mode (for ICH9R
only)
Mainboard Specifications
