MSI PRO H610M-E DDR4 User Manual

18
JCI1: Chassis Intrusion Connector
This connector allows you to connect the chassis intrusion switch cable.
Normal
(default)
Trigger the chassis
intrusion event
Using chassis intrusion detector
1. Connect the JCI1 connector to the chassis intrusion switch/ sensor on the chassis.
2. Close the chassis cover.
3. Go to BIOS > SETTINGS > Security > Chassis Intrusion Configuration.
4. Set Chassis Intrusion to Enabled.
5. Press F10 to save and exit and then press the Enter key to select Yes.
6. Once the chassis cover is opened again, a warning message will be displayed on
screen when the computer is turned on.
Resetting the chassis intrusion warning
1. Go to BIOS > SETTINGS > Security > Chassis Intrusion Configuration.
2. Set Chassis Intrusion to Reset.
3. Press F10 to save and exit and then press the Enter key to select Yes.

MSI PRO H610M-E DDR4 Specifications

General

Form Factor	Micro-ATX
Chipset	Intel H610
Memory Type	DDR4
Memory Slots	2
Max Memory	64GB
Socket	LGA 1700
PCIe x16 Slots	1
PCIe x1 Slots	1
SATA Ports	4
M.2 Slots	1
Audio	Realtek ALC897 Codec
Video Outputs	HDMI, VGA
LAN	Realtek RTL8111H
USB Ports	6 (USB 2.0), 4 (USB 3.2 Gen1)
