MSI Z270 GAMING M7 - Fan LEDs; BIOS FLASHBACK+ LED; GAME BOOST LEDs

32
Onboard LEDs
BIOS FLASHBACK+ LED
BIOS FLASHBACK+ LED
BIOS FLASHBACK+ LED indicates BIOS flash is in progress.
GAME BOOST LEDs
These LEDs indicate GAME BOOST control status.
HW GAME BOOST LED (Red)
SW GAME BOOST LED (White)
LED Color GAME BOOST control status
Red
GAME BOOST control by physical
button
White GAME BOOST control by BIOS
LED Color Fan control mode
Red PWM mode
Green DC mode
Fan LEDs
These LEDs indicate the fan control mode.
CPU_FAN1 LED
PUMP_FAN1 LED
