MTD 25B-551A700 - Assembling Your New Edger; Securing the Handles; Attaching the Starter Rope

Assembling
Your NeW
i
WARNING
i i
TheedgerbladewILL
rotatewhen thestarter
rope ispulled.
:_MPORTANT:Th_sunit
is shipped WITHOUT
GASOMNE.Aftersett ng
enginewithgasoline as
instructed inthe engine
manualpackedwithyour
unit. Besureto service
enginewiththeoi_
enclosedwiththis unit as
_nstructedintheseparate
engineman,a!,
Figure3-1:Unfoldhandleandtightenstar knobs.
Figure3-2:Pull recoilstarterthroughropeguideand tighten.
IMPORTANT:Thisunit is shipped WITHOUTGASO-
LINE.Aftersettingup the unit, serviceenginewith
gasolineas instructedinthe separateenginemanual
packedwith your unit. Also be sure to service engine
with the oil enclosed with this unit asinstructedinthe
enginemanual.
NOTE:Referenceto right or left hand side of the
edger isobservedfrom the operatingposition.
Securing the Handles
Removeanddiscardanypackagingcardboardthatmay
bepresentbetweentheupperhandleandthe lower
handle.
1. Depressthe bladecontrolat thetopoftheupper
handleandpivottheupperhandleupwarduntil it
snapsintoplace,Figure3-1.
2. Tightenthestarknobs,whicharelocatedon boththe
leftand rightsidesofthehandle.
Attaching the Starter Rope
Locatetheropeguidefoundonthe rightsideof the upper
handle.Loosen,but do NOTremove,the wing knobwhich
securesthe ropeguideto the upperhandle,Figure3-2.
1. Standbehindthe unitand holdthe bladecontrol
againsttheupperhandle.
2. Gentlypullthe starterropeoutof theengine.The
starterropewillnot pullout of the engineunlessthe
bladecontrolis depressedagainstthe upperhandle.
_1 ARNING:Theedger blade WILL rotatewhen
the starter ropeispulled.
3. Slipthe starterropethroughthetopof theropeguide.
4. Tightenthewing knobwhichsecuresthe ropeguideto
theupperhandle.
Specifications are
subject to changew thout
notification or obligation,
imagesmay not reflect
your exactmodel and are
for reference purposes
only,
6
