P25 Series of Engines
30
Fuel tank
To remove/replace the fuel tank:
1. Drain the fuel tank.
2. Disconnect the fuel lines from the carburetor.
See Figure 5.9.
3. Remove the two screws that hold the fuel tank to
the starter housing using a T-20 torx driver.
See Figure 5.10.
4. Slide the tank out to the rear.
5. Install the fuel tank by following the previous steps
in reverse order.
Figure 5.9
Disconnect the fuel lines
Figure 5.10
Screws
