Model 310
PARTS LIST FOR TILLER MODEL 310
REF.
, NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
REF.
NO.
PART
NO.
COLOR
CODE
DESCRIPTION
NEW
PART
1
_
Engine
26
712-0342 Hex Jam Nut 3/8-16 Thd.
2 710-0600
Hex Wash. Hd. Self-Tap Scr.
27 710-0599 Hex Wash. Hd. Self-Tap Scr.
5/16-24 x .50" Lg.
V4-20 x .50" Lg.
3 04958 463
Belt Cover
28
736-0270 Belleville Wash. .26 I.D. x .75
4 710-0599
Hex Wash. Hd. Self-Tap Scr.
O.D. x .060
V4-20 x .50" Lg.
29
710-0176
Hex Scr. 5/16-18 x 2.75" Lg.*
5
784-0114 Belt Keeper Brkt. Ass’y.
N
33
714-0149
Hairpin Cotter
6 710-0593
Hex Bolt 5/16-24 x 2.25" Lg.
34
—
See Tine Chart Below
(Gr. 5)
35 1545-029 Clevis Pin
B
710-0237 Hex Bolt 5/16-24 x .62" Lg.
36
710-0442
Bolt 5/16-18 x 1.5" Lg.*
M
(Gr. 5)
37 04949
463
Frame Rail—L.H.
710-0121 Hex Scr. V2-20 Thd. (Special)
38 04933 Front Brace Brkt.
H
750-0345
Spacer
39 710-0118 Hex Scr. 5/16-18 x .75" Lg.*
si
748-0282 Pulley Half
40 736-0119 L-Wash. 5/16" I.D.*
EH
748-0282 Pulley Half
41
712-0158 Hex Cent. L-Nut 5/16-18 Thd.
ii 736-0258 FI-Wash. 3/8" I.D. x 1.25"
42 04948
463 Frame Rail—R.H.
O.D. x .100
43 712-0158 Hex Cent. L-Nut 5/16-18 Thd.
12
736-0169
L-Wash. 3/8" I.D.*
44
736-0119 L-Wash. 5/16" I.D.*
13
710-0152 Hex Scr. 3/8-24 x 1.00" Lg.
45 750-0470 Spacer
17
04934
463
Idler Mounting Brkt.
46 784-0001
Tine Shield
18
738-0322 Shld. Bolt
47
—
See Tine Chart Below
19 784-0027 Idler Bracket Ass’y.
48
751-0233
Deflector
20
710-0344 Hex Scr. 3/8-16 x 1.50" Lg.
49
710-0783
Hex Self-Tap Scr. #8-32
21 756-0137
Idler Pulley
x .38" Lg.
22
736-0169 L-Wash. 3/8" I.D,*
50
736-0119 L-Wash. 5/16" I.D.*
23
712-0342
Hex Jam Nut 3/8-16 Thd.
51 712-0267
Hex Nut 5/16-18 Thd.*
24 731-0511 Trim Strip—3"
52
712-0123 Hex Nut 5/16-24 Thd.*
25 736-0169 L-Wash. 3/8" I.D.*
'For faster service obtain standard nuts, bolts, and washers locally. If these items cannot be obtained
locally, order by part number and size as shown on parts list.
(463—Top Flite Red) When ordering parts if color or finish is important, use the appropriate color code shown
at left. (e.g. Top Flite Red Finish—04943 (463).)
TINE CHART
Part No.
Description
784-0092
784-0094
784-0091
784-0093
Llnner Tine Ass’y. Comp.—R.H.
Outer Tine Ass’y. Comp.—R.H.
Inner Tine Ass’y. Comp.—L.H.
Outer Tine Ass’y. Comp.—L.H.
j\
Heavy Duty Garden Tiller Attachments Available for All-Season Use
31-0106 Depth Gauge Wheels (Pair)
31-0107 6-Tine Cultivator (Must be used with
31-0106 Depth Gauge Wheels)
31-0110 8" Furrower Opener
31-0111 15" Sweep Cultivator
31-0113 Pneumatic Tires, 13 x 5.00-6 (Pair)
31-0114 Wheel Weights (Pair)
31-0115 Tire Chains, 13 x 5.00 (2 Link) (Pair)
31-0119 Tine Cultivating Shields w/Adapters
(Pair)
31-0123 Lawn Aerator (Use with 31-0114 Wheel
Weights for added penetration)
31-0144 “V”-Bar Cultivating Kit
Kit Includes: “V”-Bar Frame, 4-Point
Cultivating Tines, Hiller/Furrower,
Depth Gauge Wheels (Pair).
31-0145 Depth Stake Cultivating Kit
Kit Includes: 8" Furrower Opener, 15"
Sweep Cultivator, 32" Leveling Rake,
Extra Depth Stake.
Note: Attachments are available through your local dealer or from the factory:
Agri-Fab Inc., 303 W. Raymond Street, Sullivan, Illinois 61951 (217) 728-4334
