MTD GCS 50/45 - TECHNICAL DATA

52
TECNICAL DATA
Mass 5,5 kg
Fuel tank capacity 0,36 l
Chain oil tank capacity 0,42 l
Bar length 45 cm
Cutting length 410 mm
Chain pitch 3/8"/9.53 inch/mm
Chain (guide thickness) 0,05"/1.27 mm
Engine sprocket wheel 6 teeth
Engine displacement 49,9 cm
3
Engine performance (ISO 7293) 2,2 kW
Specific consumption at max power 530 g/kWh
Recommended maximum engine speed 11.500 min
-1
Recommended engine speed at idling 3.400 min
-1
Vibrations
(ISO 22867 - ISO 11681-1) 6,0 m/s
2
K = 1,5
Sound pressure level
(ISO 22868 - ISO 11681-1) LpA av 103 dB(A) K = 3,0
Sound power level
(ISO 22868 - ISO 11681-1) LwA av 110 dB(A) K = 3,0
Bar: Oregon 180SDEA095
Chain: Oregon 91P061X
The “serial number” is mentioned either on the data
label on the machine or the CE declaration.
CHAIN SAW OPERATING MANUAL
GB
serial number XXXXX
ENGLISH
