MTD OEM-190-032 - Carton Contents

6
3
Carton
Contents
If you are missing
any parts, please
do not contact the
retailer where you
purchased this unit,
call MTD directly at
1-330-220-4MTD or
toll free at
1-800-800-7310.
Figure 3
Idler Assembly
Idler Pulley & Pin
Belt Keeper & Hardware
Cable Ties
Extension Spring
Undercarriage Assembly
Spare Shear Bolts
& Hex Lock Nuts
Chute Directional
Support w/ Tilt Lever
& Upper Crank Rod
Lift Handle
Assembly
Auger Housing
Assembly w/
Linkage
Extension Spring
Assembly Brackets
& Hardware
Wing Nut
Belt Keeper
& Hardware
Upper V-Belt
(754-0435)
Upper V-Belt
(754-0498)
Upper V-Belt
(754-0481)
Clamp
Cotter Pin
Self-Adhesive
Reflectors
