MTE Matrix E-Series - Filter Efficiency, Watt Loss, and Capacitor Current; Table 3-3: Filter Efficiency, Watt Loss, Capacitor Current

Matrix
®
E-Series Technical Reference Manual 380V – 480V
7 Form: MAE-TRM-E September 2020 REV. 001
Filter Efficiency, Watt Loss, and Capacitor Current
Matrix E-Series 480V, 60Hz
Table 3-3: Filter Efficiency, Watt Loss, Capacitor Current
Maximum
Output Amps
RMS
Efficiency
(%)
Typical
Power Dissipation
(Watts)
Typical
Capacitor Current
(Amps RMS)
6
98.3%
70
2.2
8
98.4%
79
2.9
11
98.3%
101
4.0
14
98.5%
113
5.0
21
98.6%
205
7.6
27
98.5%
227
9.7
34
98.7%
219
12.2
44
98.8%
289
15.8
52
99.0%
297
18.7
66
99.0% 384 23.8
83
99.1%
404
29.9
103
99.1%
425
37.1
128
99.1%
513
46.1
165
99.2%
714
59.4
208
99.2%
783
74.7
240
99.3%
821
84.6
320
99.3% 994 112.5
NOTE: Use the IEC AC-3 rating for the corresponding filter capacitor current when selecting a
contactor.
