MTE Matrix E-Series - Matrix E-Series 380 V - 415 V Torque Ratings; Table 5-2: Torque Ratings 380 V - 415 V

Matrix
®
E-Series Technical Reference Manual 380V – 480V
Form: MAE-TRM-E September 2020 REV. 001 20
Matrix E-Series 380V – 415V Torque Ratings
Table 5-2: Torque Ratings 380V – 415V
Filter
Rating
(Amps)
Reactor Terminals
Capacitor Terminals
U4-V4-W4
Input /Output Power
U1-V1-W1 / U2-V2-W2
Interconnect
Reactor
U4-V4-W4
Capacitor
Part Number
Minimum
Interconnect
Wire Gauge
(AWG)
Terminal
Torque
(in-lbs.)
Recommended
Minimum Wire
Gauge
(AWG)
Terminal
Torque
(in-lbs.)
Terminal
Torque
(in-lbs.)
6 14-6 16 16 CAP-349TP 14 23
8 14-6 16 16 CAP-365TP 14 23
11 14-6 16 16 CAP-366TP 14 23
14 14-6 16 16 CAP-342TP 14 23
21 14-6 16 16 CAP-344TP 14 23
27 14-6 16 16 CAP-345TP 14 23
34 14-6 16 16 CAP-346TP 12 23
44 14-6 16 16 CAP-347TP 12 23
52 Flat copper tab N/A 16
CAP-346TP/
CAP-342TP
10 23
66 Flat copper tab N/A 16
CAP-347TP/
CAP-345TP
10 23
83 Flat copper tab N/A 16 CAP-347TP (2) 10 23
103 Flat copper tab N/A 16 CAP-348TP (2) 10 23
128 Flat copper tab N/A N/A CAP-359TP (2) 10 23
165 Flat copper tab N/A N/A
CAP-359TP (2)
/ CAP-347TP
10 23
208 Flat copper tab N/A N/A
CAP-360TP (2)
/ CAP-348TP
8 23
240 Flat copper tab N/A N/A
CAP-360TP (3)
/ CAP-340TP
4 23
320 Flat copper tab N/A N/A CAP-360TP (4) 2 23
Note: To prevent flexing or bending of the coil windings attached to the flat copper terminal tabs
on the Matrix E-Series reactor, use two wrenches to tighten customer provided cable mounting
hardware.
