3. MATRIX E-Series PERFORMANCE DATA
Performance Specifications
Table 3-1: Performance Specifications
Service Load Condition
Load: 6-pulse variable torque rectifier only
Input Voltage
380-415V +/- 10%; 50 + 0.75Hz. 3-phase
480V +/- 10%; 60 + 0.75Hz; 3-phase
Current Range
6A – 320A (1.1 KW – 150 KW; 3HP – 250HP)
Maximum THID
With DC Link Choke or Reactor
8% @ full load; 12% @ 40% load
Without DC Link Choke or Reactor
12% @ full load; 17% @ 40% load
System Power Conditions at Rated Current
THVD: <2%
Line Voltage Unbalance: <1%
Source Impedance
Maximum: 6%
Minimum: 1.5%
Maximum output voltage at no load (RMS Peak)
+5%
Minimum output voltage at full load (RMS Peak)
-5%
Service Factor
1.00
Ambient Temperature (Operating)
Open Panel Filters
-40 to +50 degrees C
Storage Temperature
-40 to +90 degrees C
Insertion Loss @ Full Load
<5%
Efficiency
>98%
Altitude without Derating
3,300 Feet above sea level.
Relative Humidity
0 to 95% non-condensing
Current Rating (Overload)
150% for 1-minute duration; once per hour
Over Voltage
Category II
Fan Cooling:
 For units 21 Amps and above: Proper cooling airflow must be provided at a minimum of 400
linear feet/min.
