MTE Matrix E-Series - Matrix E-Series 380 V - 415 V Selection Tables; Table 4-1: Matrix E-Series 380 V - 415 V Open Panel

Matrix
®
E-Series Technical Reference Manual 380V – 480V
13 Form: MAE-TRM-E September 2020 REV. 001
Matrix E-Series 380V – 415V Selection Tables
Table 4-1: Matrix E-Series 380V – 415V Open Panel
Filter
Amps
Rating
Part
Number
App.
Wt.
(lbs.)
App.
Wt.
(kg)
Reactor Dimensions
(H x W x D)
Capacitor(s) Dimensions
(H x W)
(in.) (mm) (in.) (mm)
6 MAEP0006C 13
6 8.2 x 6.9 x 3.5 208 x 175 x 89 7.5 x 3.0 191 x 76
8 MAEP0008C 18
8 9.8 x 6.9 x 3.5 249 x 175 x 89 7.5 x 3.9 191 x 99
11 MAEP0011C 27
12 9.8 x 6.9 x 4.1 249 x 175 x 104 7.5 x 3.9 191 x 99
14 MAEP0014C 27
12 9.8 x 6.9 x 4.1 249 x 175 x 104 7.5 x 3.9 191 x 99
21 MAEP0021C 30
14 12.0 x 7.1 x 5.4 305 x 180 x 137 7.5 x 4.6 191 x 117
27 MAEP0027C 36
16 12.0 x 7.1 x 5.6 305 x 180 x 142 9.1 x 4.6 231 x 117
34 MAEP0034C 41
19 12.0 x 7.1 x 6.1 305 x 180 x 155 9.1 x 4.6 231 x 117
44 MAEP0044C 43
20 12.0 x 7.1 x 6.1 305 x 180 x 155 10.6 x 4.6 269 x 117
52 MAEP0052C 55
25 14.5 x 9.6 x 6.9 368 x 244 x 175
9.1 x 4.6 /
7.5 x 3.9
231 x 117 /
191 x 99
66 MAEP0066C 60
27 14.6 x 9.6 x 6.7 371 x 244 x 170
10.6 x 4.6 /
9.1 x 4.6
269 x 117 /
231 x 117
83 MAEP0083C 74
34 14.5 x 9.6 x 7.5 368 x 244 x 191 10.6 x 4.6 (2) 269 x 117 (2)
103 MAEP0103C 86
39 14.6 x 9.6 x 8.3 371 x 244 x 211 10.6 x 4.6 (2) 269 x 117 (2)
128 MAEP0128C 97
44 14.9 x 9.6 x 8.8 378 x 244 x 224 10.6 x 4.6 (2) 269 x 117 (2)
165 MAEP0165C 119
54 16.9 x 11.0 x 9.0 429 x 279 x 229 10.6 x 4.6 (3) 269 x 117 (3)
208 MAEP0208C 136
62 17.1 x 11.0 x 9.3 434 x 279 x 236 10.6 x 4.6 (3) 269 x 117 (3)
240 MAEP0240C 166
75 16.8 x 11.0 x 10.5 427 x 279 x 267
7.5 x 3.0 (3) /
10.6 x 4.6
191 x 76 (3) /
269 x 117
320 MAEP0320C 181
82 17.1 x 11.0 x 10.4 434 x 279 x 264 10.6 x 4.6 (4) 269 x 117 (4)
NOTE: Approximate weight of filter above includes weight of reactor and accompany capacitor(s).
NOTE: Reference drawings can be accessed by clicking on the part number.
