Sine Wave 2-8 kHz Series A Filter
21 Part No. INSTR-020 REL. 080310
Enclosed Units
Table 5
Enclosure
Indicator
Width Height Depth
Cab Part
No.
NEMA
Type
Figure
GA
13 13 13 Cab 13V NEMA 1 8
GB
17 24 18 Cab 17V NEMA 1 9
GC
27 47 25 Cab 26C NEMA 1 -2 12
GD
31 72 31 Cab 30C NEMA 1 -2 13
GE
43 72 25 Cab 42C NEMA 1 -2 14
WA
12.5 24 18 Cab 12C NEMA 3R 10
WB
17.5 31 21 Cab 17C NEMA 3R 11
WC
26.5 47 30 Cab 26C NEMA 3R 12
WD
30.5 72 40 Cab 30C NEMA 3R 13
WE
43 72 34 Cab 42C NEMA 3R 14
See Mechanical Data for enclosed weights.
