Sine Wave 2-8 kHz Series A Filter
22 Part No. INSTR-020 REL. 080310
Enclosed Units By Current
Table 6
General Purpose
Cabinets
200– 230 VAC
General Purpose
Cabinets
380 – 480 VAC
General Purpose Cabinets
550– 600VAC
Filter
Current
Rating
NEMA 1 NEMA 3R NEMA 1 NEMA 3R NEMA 1 NEMA 3R
2
CAB-13V CAB-12C
CAB-13V CAB-12C CAB-13V CAB-12C
3
CAB-13V CAB-12C
CAB-13V CAB-12C CAB-13V CAB-12C
5
CAB-13V CAB-12C
CAB-13V CAB-12C CAB-13V CAB-12C
7
CAB-13V CAB-12C
CAB-13V CAB-12C CAB-13V CAB-12C
9
CAB-13V CAB-12C CAB-13V CAB-12C CAB-13V CAB-12C
12
CAB-13V CAB-12C CAB-13V CAB-12C CAB-13V CAB-12C
17
CAB-13V CAB-12C CAB-13V CAB-12C CAB-17V CAB-17C
22
CAB-17V CAB-17C CAB-17V CAB-17C CAB-17V CAB-17C
27
- - CAB-17V CAB-17C CAB-17V CAB-17C
30
CAB-17V CAB-17C - - - -
35
CAB-17V CAB-17C CAB-17V CAB-17C CAB-17V CAB-17C
45
CAB-17V CAB-17C CAB-17V CAB-17C CAB-17V CAB-17C
55
CAB-17V CAB-17C CAB-17V CAB-17C CAB-26C CAB-26C
65
- - CAB-17V CAB-17C CAB-26C CAB-26C
70
CAB-17V CAB-17C - - - -
80
- - CAB-26C CAB-26C CAB-26C CAB-26C
85
CAB-26C CAB-26C - - - -
110
CAB-26C CAB-26C CAB-26C CAB-26C CAB-26C CAB-26C
130
- - CAB-26C CAB-26C CAB-30C CAB-30C
135
CAB-26C CAB-26C - - - -
160
CAB-26C CAB-26C CAB-26C CAB-26C CAB-30C CAB-30C
200
CAB-30C CAB-30C CAB-30C CAB-30C CAB-30C CAB-30C
250
CAB-30C CAB-30C CAB-30C CAB-30C CAB-30C CAB-30C
305
- - CAB-30C CAB-30C CAB-30C CAB-30C
320
CAB-30C CAB-30C - - - -
365
- -
CAB-30C CAB-30C CAB-30C CAB-30C
415
- -
CAB-30C CAB-30C CAB-42C CAB-42C
515
- -
CAB-30C CAB-30C CAB-42C CAB-42C
600
- -
CAB-42C CAB-42C CAB-42C CAB-42C
720
- -
CAB-42C CAB-42C CAB-42C CAB-42C
Mounting dimensions and outline drawings for filters mounted in NEMA 1, 3R
Enclosures follow
