Electromagnetic Compatibility
Guidance and manufacturer’s declaration - electromagnetic Immunity
The Dolito is intended for use in the electromagnetic environment specied below. The customer or the
user of the Dolito should assure that it is used in such an environment
Immunity Test
IEC 60601
Test level
Compliance level
Electromagnetic
environment - guidance
Electrostatic
discharge (ESD)
IEC 61000-4-2
±8 kV contact
±2 kV, ±4 kV, ±8 kV, ±15
kV air
±8 kV contact
±2 kV, ±4 kV, ±8 kV,
±15 kV air
Floors should be wood, con-
crete or ceramic tile. If oors
are covered with synthetic
material, the relative humidi-
ty should be at least 30 %
Electrical fast
transient/burst
IEC 61000-4-4
Power supply lines: ±2
kV
input/output lines: ±1 kV
Not
Applicable
Dolito is powered by
batteries
Surge
IEC 61000-4-5
line(s) to line(s): ±1 kV.
line(s) to earth: ±2 kV.
100 kHz repetition
frequency
Not
Applicable
Dolito is powered by
batteries
Voltage dips,
short inter-
ruptions and
voltage variations
on power supply
input lines
IEC 61000-4-11
At 0º, 45 º, 90 º, 135 º,
180 º, 225º, 270 º and
315 º phases
0% U
T
for 0.5 cycle
And at single phase 0°
0% U
T
for 1 cycle
70% U
T
for 25/30 cycles
0% U
T
for 250 cycles
0% U
T
for 300 cycles
Not
Applicable
Dolito is powered by
batteries
Power frequency
(50/60Hz)
magnetic eld
IEC 61000-4-8
30 A/m
50 Hz / 60 Hz
30 A/m
50 Hz / 60 Hz
Power frequency magnetic
elds should be at levels cha-
racteristic of a typical locati-
on in a typical commercial or
hospital environment.
Conduced RF
IEC61000-4-6
150 KHz to 80 MHz:
3 Vrms
6 Vrms (in ISM and
amateur radio bands)
80 % AM at 1 kHz
150 KHz to 80 MHz:
3 Vrms
6 Vrms (in ISM and
amateur radio bands)
80 % AM at 1 kHz
Interference may occur in the
vicinity of equipment
marked with the
following symbol:
Radiated RF
IEC61000-4-3
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
10 V/m
80 MHz – 2,7 GHz
80 % AM at 1 kHz
NOTE 1: U
T
is the a.c. mains voltage prior to application of the test level.
NOTE 2: At 80 MHz the higher frequency range applies.
NOTE 3: These guidelines may not apply in all situations. Electromagnetic propagation is aected by
absorption and reection from structures, objects and people.
