Temposonics

E-Series CANopen

Operation Manual

Multi position measurement

The minimum distance between the magnets is 75 mm (3 in.).

Temposonics

E-Series EP with U-magnet Temposonics

E-Series EP with block magnet

(3)

Temposonics

E-Series EP with magnet slider S & V Temposonics

E-Series EL with magnet slider S & V

(3)

Temposonics

E-Series EL with block magnet Temposonics

E-Series EH with ring or U-magnet

(3)

Fig. 15: Minimum distance for multi position measurement

Controlling design dimensions are in millimeters and measurements in ( ) are in inches
