I 13 I
4.4 Styles and installation of R-Series RD4
Temposonics
®
RD4 is a high-performance position sensor with a detached electronics, which allows a flexible installation. The sensor is completely
modular in mechanic and electronic design. The sensor rod with the built-in waveguide is connected via a short cable with the electronics.
Temposonics
®
RD4 is an ideal sensor where space is a problem while still allowing for easy maintenance. The sensor can either be used for integration
into a fluid power cylinder or in external industrial applications.
Electronics with side cable entry for the measuring rod
Fig. 20: RD4 style dimensional drawing with side mount electronics
Controlling design dimensions are always in metric units and measurements in ( ) are in inches
Unless otherwise stated, apply to the general tolerances according to DIN ISO 2768-m
14
(0.55)
* Tolerance +8 (0.31) / −5 (0.2) up to 7620 (300) stroke length
Tolerance +15 (0.59) / −5 (0.2) > 7620 (300) stroke length
Tolerance of total length has no influence on the stroke length
50
(1.97)
68
(2.68)
35.6
(1.4)
2
(0.08)
49
45
2
Ø 5.5
M5
28
Measuring range
25…5080
66
45
(1.77)
12
(0.47)
66
(2.6)
14.5
(0.57)
45.4
(1.79)
129
(5.07)
28
(1.1)
Measuring range
25…5080
(1…200)
49
(1.93)
9
(0.36)
Ø 5.5 (0.21)
M5 or #10
screw
128
28
50
35.6
68
9.5
O-ring
51
(2)
51
(2)
63.5/66*
(2.5/2.6)
Measuring range
25…7620
(1…300)
Measuring length
100…10060
(4…396)
Measuring length
100…10060
(4…396)
Total length*
133
(5.24)
Ø 10
(Ø 0.39)
46
(1.75)
53
(2)
25
(0.98)
*> 5000 mm
Stroke length
94
(3.7)
133
(5.24)
45
(1.8)
94
(3.7)
45
(1.77)
49
(1.93)
123
(4.84)
7
(0.28)
61
(2.4)
11.5
(0.45)
