Temposonics
®
R-Series EtherNet/IP
TM
Operation Manual
I 5 I
3.2 Order structure of R-Series RH
*/ Non Standard stroke lengths are available; must be encoded in 5 mm / 0.1 in. increments
4/ Note: Please specify magnet numbers for your sensing application and order separately
Temposonics
®
order code
a Sensor model
R H
Rod
b Design
M
Flange M18×1.5 (Standard)
V
Flange M18×1.5 with Fluoroelastomer housing-seal
D
Flange M18×1.5 bushing on rod end
R
Flange M18×1.5 thread M4 at rod end
J
Flange M22×1.5 rod Ø 12.7 mm, 800 bar
S
Flange M¾"×16UNF - 3A
B
B Sensor cartridge only
(no flange or pressure tube, stroke length <1830 mm (72 in.))
d Connection type
D 5 6
2 × 4 pin M12 female, 1 × 4 pin M8 male
e Operation voltage
1
+24 VDC (−15 / +20 %)
c Stroke length
X X X X M
0025…7620 mm
X X X X
U
001…300 in.
Standard stroke length (mm)*
Stroke length Ordering steps
25 … 500 mm 5 mm
500 … 750 mm 10 mm
750…1000 mm 25 mm
1000…2500 mm 50 mm
2500…5080 mm 100 mm
5000…7620 mm 250 mm
Standard stroke length (in.)*
Stroke length Ordering steps
1 … 20 in. 0.2 in.
20 … 30 in. 0.4 in.
30 … 40 in. 1 in.
40…100 in. 2 in.
100…200 in. 4 in.
200…300 in. 10 in.
.
f Output
N 1 0 1
EtherNet/IP™
Optional: for multi-position measurement only
(Order additional magnets seperately)
g Magnet number for multi-position measurement
4
Z X X
02…20 magnets
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
R H
D 5 6
1
N 1 0
1
a b c d e
f
g
