MTS Exceed™ Series 40 Product Manual
24
Load Frame Components
Introduction
Load Frame Components
The following figures show the various components for the single-column and
two-column load frames. To familiarize yourself with the various components of
your frame, refer to the figure that shows your model number.
For dimensions, see the specification tables in the “Specifications” on page 30.
Model E42.503 - Rated Force Capacity 5 kN
Limit Rod
Upper Limit Stop
Limit Switch Actuator
Lower Limit Stop
Power Switch
Power Cord
Handset
Leveling Foot
Emergency Stop
Base
Base Adapter
Mat
Adapter
Pin
Load Cell
(inside)
Crosshead
Ball Screw Cover
Top Beam
Column Cover
Controller
0Exceed product manual.book Page 24 Wednesday, August 27, 2014 2:55 PM
