Model E42.503 Accessory Mounting Dimensions
MTS Exceed™ Series 40 Product Manual Installation
55
Model E42.503 Accessory Mounting Dimensions
Base beam
Crosshead
Φ50
4-M6x12
Model E42.503 Base Beam Mounting Dimensions
Model E42.503 Crosshead Mounting Dimensions
60
+0.03
Φ12.5THRU
30
+0.03
+0.06
+0.06
vΦ25x16
0Exceed product manual.book Page 55 Wednesday, August 27, 2014 2:55 PM
