MTS Exceed™ Series 40 Product Manual
62
Model E45.305 Accessory Mounting Dimensions
Installation
Model E45.305 Accessory Mounting Dimensions
Base beam
Crosshead
8-M12x25
Φ128
vΦ156x28
580 Horizontal Clearance
Model E45.305 Base Beam Mounting Dimensions
8-M10x25
Φ116.8
Model E45.305 Underside of Crosshead Mounting Dimensions
