Load Frame Components
MTS Exceed™ Series 40 Product Manual Introduction
29
Model E45.605 Rated Force Capacity 600kN
Connecting screw rod
(Under of crosshead)
Lower Plate
Upper Plate
Controller
Power Switch
Emergency Stop
Lower Limit
Stop
Handset
Upper Limit Stop
Limit Switch
Actuator
Limit Rod
Top Beam
Base
Adapter
Crosshead
Load Cell
Ball Screw Cover
Column Cover
