MTS Systems FlexTest SE User Manual

MTS 793 Controller Hardware
FlexTest IIm Controller Connections
164
Single-valve
connection
Dual-valve
connection
A
B
C
D
9
11
+ Valve
Command 1
– Valve
Command 1
9
11
A
B
C
D
A
B
C
D
+ Valve
Command 1
– Valve
Command 1
Shown for valves phased the
same hydraulically. For valves
phased opposite hydraulically,
reverse A and D on P2.
P0
P1
P2
