MTS 793 Controller Hardware
202
Interlock function Power must be applied to all Controllers in the chain for proper
interlock operation. If power is not applied to any one of the
Controllers, you will not be able to clear an interlock condition in any
of the Controllers.
Also, if a cable becomes disconnected from a dependent controller’s
Box In connector, or if a cable is inadvertently connected to the Box
In connector on the master controller, an interlock is set which cannot
be reset until all controllers are restarted.
Cable Part Numbers
System cables The following is a list of the most common cables, see the System
Cable/Jumper Plug 493 Package Selection drawing (MTS PN 700-000-
656) for the most current and additional cable part numbers.
Model 493.02 Chassis Cables (part 1 of 2)
C
ABLE DESCRIPTION PART
N
UMBER
*
MODULE
C
ONNECTOR
JUMPER
P
LUG
†
Servovalve 252.xx single 039-708-3XX 493.40 J4–J7 N/A
Servovalve 252.xx dual 039-708-4XX 493.40 J4–J7 N/A
Servovalve 256.xx 3-stage
Valve
Valve LVDT
Calibration Cable Package
Y Adapter—Servovalve/Valve LVDT
(required for 256.xx or 257.xx servovalves)
055-439-6XX
039-708-6XX
100-026--213
039-710-501
493.40 J4–J7
493.40 J4–J7
493.40 J3
493.40 J4–J7
N/A
N/A
Workstation Link (Ethernet cable) 051-996-8XX
10/100
‡
N/A
System ground (table top)
System ground (rack mount)
005-402-3XX
039-709-2XX gnd lug
N/A
Hydraulic Power Unit (HPU) (see “Hydraulic
Configurations” on page 221 for more
information)
039-713-7XX 493.42 J25 039-713-301
Hydraulic Service Manifold (HSM) 039-701-5XX 493.42 J28 N/A
Emergency Stop (E-STOP) 493.42 J29 100-007-947
Interlock (Intlk) Per System 493.42 J43 100-057-245
