Operation
42 Series 505G2 SilentFlo™ Hydraulic Power Unit
Name and Location Description
operation.
Remote Operation - gray: Indicates the HPU is not in remote
operation.
Remote Operation - green: Indicates the HPU is in remote
operation.
In remote operation, the local Run and High Pressure buttons
are disabled
Pump Hours Indicator/Display: Indicates total running time of the HPU.
Oil Pressure
Part of the Analog
Option;only displayed if the
Analog Option was
purchased.
Indicator/Display: Indicates output pressure of the HPU.
Oil Temp(erature)
Part of the Analog
Option;only displayed if the
Analog Option was
purchased.
Indicator/Display: Indicates the temperature of the hydraulic
fluid in the reservoir.
Oil Level
Part of the Analog
Option;only displayed if the
Analog Option was
purchased.
Indicator/Display: Displays the level of the hydraulic fluid in
the reservoir in 1/8 increments. The level is relative to the
bottom of the sensor, not the bottom of the reservoir.
