Owner’s Manual - TR100.4
Introduction
Thank you for purchasing an MTX Audio Hi-Performance amplifier. Proper installation matched with MTX speak-
ers and subwoofers provide superior sound and performance for endless hours of waking the neighbors, slam-
min' your friends or flat out stomping wanna-be players. Congrats and enjoy the ultimate audio experience with
MTX !
Specifications :
• 4-Channel Class-AB Amplier
• CEA2006 certied Power Output :
- 70 watts RMS x 4-channel at 2 ohm and THD+N ≤1%
- 40 watts RMS x 4-channel at 4 ohm and THD+N ≤1%
- 140 watts RMS x 2-channel at 4 ohm and THD+N ≤1%
• Crossover :
- High pass 12dB/oct @80Hz
- Low pass 12dB/oct @80Hz
• Signal-to-Noise Ratio (1 watt) : > 80dB
• THD+Noise (Distortion) (1 watt) : ≤ 1%
• Frequency Response (±1dB) : 10Hz-50000Hz
• Maximum Input Signal : 6V
• Maximum Sensitivity : 200mV
• Dimensions : 337x165x53mm
• High level inputs
Control Panel
