Switching over the transmission with
a shuttle gear (if installed)
Switch the gearbox and the shuttle gear in
accordance with the changeover scheme.
Using the tractor in the “shuttle” mode
makes it possible to change quickly the di -
rection of the tractor motion by means of
the lever (2) without using the change
gear lever (1).
The shuttle gear control lever (2) is
located under the steering column
(unlike the reducing gear lever, it is
bent to the left) and has two posi-
tions:
• “Reverse OFF” – foremost position;
• “ Reverse ON” – rearmost position.
IMPORTANT! When changing motion di -
rection, step on the clutch pedal and stop
the tractor.
NOTE: When the shuttle gear is engaged
and the change gear lever (1) is set to the
gear I-R and II-R, the tractor moves for -
ward.
