Copyright Müller-Elektronik GmbH u. Co. UNI-Control S Installation and User´s Guide (01/95) Seite - 21 -
|
v
|
+------------------------------------------+
|
v /-----------------/-----+
+-------------------------/-----------------/ | Left:
| M a c h i n e | M e n u | T1 |---> Ms Enter the working width via the
|-------------------------|-----------------|------| decimal keyboard
| W o r k i n g - | | T2 |
|-------------------------|-----------------|------| Right:
| w i d t h : | | T3 | Press the T1 key for menu selection.
|-------------------------|-----------------|------| Press the T4 key to proceed to the
next
| 1 6 . 0 0 m | N e x t | T4 |---+ display.
+-------------------------\-----------------\ | |
\-----------------\-----+ |
|
|
v
+-----------------------------------------+
| ↑
| |
v /-----------------/-----+ | Left:
+-------------------------/-----------------/ | | Enter the impulses/l via the decimal
| M a c h i n e | M e n ü | T1 |---> Ms | keyboard
|-------------------------|-----------------|------| |
| I m p u l s e s / l l | T2 | |
|-------------------------|-----------------|------| | Right:
| | C a l i b r a t | T3 |---+ | Press the T1 key for menu selection.
|-------------------------|-----------------|------| | | Press the T3 key for the calibration
of
| 2 8 3 , 0 0 | N e x t | T4 |---------+ | the liquid flow meter, if required
+-------------------------\-----------------\ | | | | Press the T4 key to proceed to the
next
\-----------------\-----+ | | | display.
| | |
| | |
+-------------------------------+ | |
| | |
v /-----------------/-----+ | | Description of the calibration
process
+-------------------------/-----------------/ | | | Right:
| C a l i b r a t io n | B a c k | T1 |---------|-->+ Press the T1 key to interrupt the
|-------------------------|-----------------|------| | calibration process.
| C a l i b r a t e , d e l t e r m i n e | T2 | |
|-------------------------|-----------------|------| |
| l i q u i d s i n l ,| e n t e r | T3 | |
|-------------------------|-----------------|------| |
| l i t r e s, p r e s s "| I n p u t " | T4 | |
+-------------------------\-----------------\ | |
| \-----------------\-----+ |
| |
After 1st impulse |
| |
| |
v /-----------------/-----+ | After switching on the field sprayer
+-------------------------/-----------------/ | | and after the 1st impulse from the
| C a l i b r a t io n | | T1 | | liquid flow meter, the display as
shown
|-------------------------|-----------------|------| | on the left is seen. The impulses are
| I m p u l s e s / l | | T2 | | counted.At least 500 litres should be
|-------------------------|-----------------|------| | sprayed.
| 2 8 I m p . | | T3 | |
|-------------------------|-----------------|------| |
| 0 . 0 0 l | | T4 | |
+-------------------------\-----------------\ | |
| \-----------------\-----+ |
| |
| |
v /-----------------/-----+ |
+-------------------------/-----------------/ | | After about 500 l have been sprayed,
the
| C a l i b r a t io n | | T1 | | exact quantity should be determined
and
|-------------------------|-----------------|------| | entered via the decimal keyboard.
| I m p u l s e s / l | | T2 | |
|-------------------------|-----------------|------| |
| 2 5 9 3 2 5 I m p . | | T3 | |
|-------------------------|-----------------|------| |
| 5 1 2 . 5 0 l | | T4 | |
+-------------------------\-----------------\ | |
| \-----------------\-----+ |
| |
| |
v v
