Seite - 30 - Copyright Müller-Elektronik GmbH u. Co. UNI-Control S Installation and User´s Guide (01/95)
3.4.2 Example 2: Program PNEUMATIC FERTILIZER SPEADER
The features causing this program to be different to that of the field sprayer are described below :
Switching on routine
Switch on
|
|<------------------------------+
v /-----------------/-----+ |
+-------------------------/-----------------/ | | Left
| 2 3 : 1 1 : 8 7 | H o l l a n d s | T1 |---+ "Pneumatic fertilizer spreader
|-------------------------|-----------------|------| | installed" appears on the display.
The
| 1 : 0 0 | F r a n c a i s | T2 |---+ program and the machine data entered
are
|-------------------------|-----------------|------| | activated.
|P n. S p r e a d e r | E n g l i s h | T3 |---+
|-------------------------|-----------------|------| |
| i n s t a l l e d | D e u t s c h | T4 |---+
+-------------------------\-----------------\ |
| \-----------------\-----+
|
|
Data block ORDER
This block is identical to the field sprayer program.
Datenblock MACHINE
This block is to a large extent identical to the field sprayer program. The control chest type inquiry is
omitted. Instead of impulses/l the figure impulses/kg is to be determined.
|
|
v /-----------------/-----+
+-------------------------/-----------------/ | Left:
| M a c h i n e | M e n u | T1 |---> Ms The impulses/kg from the last
|-------------------------|-----------------|------| calibration test are displayed. If
the
| I m p u l s e / k g | | T2 | impulses/kg figure is known, it can
be
|-------------------------|-----------------|------| entered via the decimal keyboard.
| | C a l i b r a t | T3 |---+
|-------------------------|-----------------|------| | Right
| 2 6 2 , 5 0 | N e x t | T4 |---+----+ Before the calibration test begins
the
+-------------------------\-----------------\ | | | dosage cylinder must be switched on
so
\-----------------\-----+ | | that it can be filled.
| | Press the T3 key for the calibration
+-------------------------------+ | function.
| |
v /-----------------/-----+ |
+-------------------------/-----------------/ | | Left:
| C a l i b r a t i o n | B a c k | T1 | | The calibration process is described.
|------------------------|------------------|------| |
| c a l i b r a t e , |d e t e r m i n e | T2 | | Right:
|------------------------|------------------|------| | Press the T1 key to exit the
calibration
| k g , p u t i n k|g a n d | T3 | | function.
|------------------------|------------------|------| |
| P r e s s " I n p u t|"! | T4 | |
+------------------------\------------------\ | |
| \------------------\-----+ |
| |
After 1st impulse |
+-----------<------------------------+
|
v /-----------------/-----+
+-------------------------/-----------------/ | Left:
| C a l i b r a t i o n | | T1 | A bin is placed under the dosage
|------------------------|------------------|------| cylinder and the f ertilizer spreader
is
| I m p u l s e s / k g | | T2 | switched on. The computer goes
|------------------------|------------------|------| automatically to the display shown on
| 2 8 I m p .| | T3 | the left. The impulses determined by
the
|------------------------|------------------|------| actuation of the dosage shaft are
| 0 , 0 0 k g | | T4 | counted.
+------------------------\------------------\ |
