Seite - 4 - Copyright Müller-Elektronik GmbH u. Co. UNI-Control S Installation and User´s Guide (01/95)

1 Summary

[1] UNI-Control S computer (art. no.: 302531); with chip card (art. no.: 302532).

[2] Tractor plug (at the back)

Connects tractor signal distributor with the tractor-specific sensors.

[3] Machine plug on the UNI-Control S

Connects switch box to machine adapter.

[4] Machine plug on the switch box or on the machine adapter. Connection to UNI-Control S.

[5] Switch box (art. no.: see price list)

Operating panel of the attached machines (e.g. field sprayer) with connection to UNI-Control S.

[10] Bracket profile slide (art. no.: 312228)

Receiver for the UNI-Control S computer and the switch box or machine adapter.

[11] Leading channel

for UNI-Control S and the switch box or machine adapter.

[12] Binding screws

to secure the computer, the switch box or machine adapter.

[13] Bracket S (Art.-No.: 312226 (incl. profile slide [10]))

Holds die profile slide.

[14] Computer console (art. no.: 312227)

Mounted to the tractor cabin. Includes the bracket with profile slide and battery connection fo

the switch box or the machine adapter.

[15] Battery connection cable (art. no.: 312155)

for the voltage supply to the switch box or machine adapter. Connection to the 12-volt battery.

[16] Tractor signal distributor S (art. no. see price list)

Junction box for the tractor-specific sensors and the battery connection cable.

[17] Battery connection cable for the voltage supply to the UNI-Control S.

[18] Sensor Y (Working position) (art. no.: 312089)

to record the working position (z. B. at the 3-point hydraulics).

[19] Power take-off shaft rotation sensor (art. no.: 302580)

to record shaft speeds at rpm.

[20] Sensor X (cardan shaft / wheel) (art. no.: 312580)

to record the forward speed, impulse taken from the cardan shaft or front wheel of the tractor.

[21] Radar device (art. no.: 302583)

for non-slip speed recording.

[22] Plug for tractor signal socket

Takes signals from the sensors already installed on the tractor.

[23] Plug for tractor signal socket

Takes signals from the sensors already installed on the tractor. (ISO -11786)
