Seite - 32 - Copyright Müller-Elektronik GmbH u. Co. UNI-Control S Installation and User´s Guide (01/95)
3.4.3 Example 3: Program TRACTOR
The tractor program is similar to the field sprayer program.
The diverging features are described below :
Switching on routine
Switch on
|<------------------------------+
v /-----------------/-----+ |
+-------------------------/-----------------/ | | Left:
| 2 3 : 1 1 : 8 7 | H o l l a n d s | T1 |---+ "Tractor installed" appears on
|-------------------------|-----------------|------| | the left -hand side of the
| 1 : 0 0 | F r a n c a i s | T2 |---+ display
|-------------------------|-----------------|------| |
| T r a c t o r | E n g l i s h | T3 |---+
|-------------------------|-----------------|------| |
| i n s t a l l e d | D e u t s c h | T4 |---+
+-------------------------\-----------------\ |
\-----------------\-----+
Data block ORDER
This block is identical to the field sprayer program.
Data block MACHINE
This block is to a large extent identical to the field sprayer program. The numberof nozzles/boom-
sections, type of control chest and impulses/l do not have to be entered. Up to 16 additional shaft speeds
in the region of 20 to 10,000 rpm can be monitored via the machine plug. The shaft speed input is
activated by entering the name via the decimal keyboard (at least one letter or one number).
|
|
v /-----------------/-----+
+-------------------------/-----------------/ | Left:
| M a c h i n e | M e nu | T1 |---> Ms The shaft is specified (e.g.
|------------------------|------------------|------| chopper)via the decimal keyboard
| N a m e o f t h e | | T2 |
|------------------------|------------------|------|
| s h a f t 1 | | T3 |
|------------------------|------------------|------|
| C H O P P E R | N e x t | T4 |---------+
+-------------------------\-----------------\ | |
\-----------------\-----+ |
|
|
|
|
I n the tractor program it is possible to retrieve the working position from the tractor distributor via the
tractor plug or from the machine distibutor via the machine plug.
|
|
|
v /-----------------/-----+
+-------------------------/-----------------/ | Right:
| M a c h i n e | M e n u | T1 |---> Ms Press the T1 key for menu selection.
|------------------------|------------------|------| Press the T2 key to determine the
| W o r k i n g - | - > Y e s | T2 | working position via the tractor
plug.
|------------------------|------------------|------| Press the T3 key to determine the
| s e n s o r o f | N o | T3 | working position via the tractor
plug.
|------------------------|------------------|------|
| t r a c t o r | N e x t | T4 |---+
+-------------------------\-----------------\ | |
\-----------------\-----+ |
|
|
|
|
|
