Copyright Müller-Elektronik GmbH u. Co. UNI-Control S Installation and User´s Guide (01/95) Seite - 29 -
Function data
The 3 function keys next to the decimal keyboard enable the required figures to be displayed simply by
pressing a key.
+---------+
| kg l |
+----------------------------------------| ----- |
| | ha |
v /-----------------/-----+ +---------+
+-------------------------/-----------------/ | Left:
| 1 2 2 , 5 l | | T1 | Displays the current order, the
|-------------------------|-----------------|------| quantity sprayed and the worked
| | T o t a l | T2 |---------+ area.
|-------------------------|-----------------|------| |
| 6 , 1 2 5 0 h a | | T3 | | Right:
|-------------------------|-----------------|------| | Press the T2 key to display the total
| | N e x t | T4 |---> Op | quantity sprayed and the worked
+-------------------------\-----------------\ | | area.
\-----------------\-----+ | Press the T4 key to go back to the
| operation data.
|
|
+-------------------------------------+
| ↑
| |
v /-----------------/-----+ |
+-------------------------/-----------------/ | | Left:
| 2 4 8 1 0 l | D e l e t e | T1 |-->| Displays the total quantity sprayed
and
|-------------------------|-----------------|------| | the worked area.
| | | T2 | | (e.g. within one season).
|-------------------------|-----------------|------| |
| 1 0 3 , 3 7 5 h a | D e l e t e | T3 |---+ Right:
|-------------------------|-----------------|------| Press the T1 and T3 keys to delete
the
| | N e x t | T4 |---> Op figures shown on the left.
+-------------------------\-----------------\ | Press the T4 key to go back to the
\-----------------\-----+ operation data.
+---------+
| km |
+----------------------------------------| ----- |
| | h |
v /-----------------/-----+ +---------+
+-------------------------/-----------------/ | Left:
| 1 2 7 . 3 2 1 k m | | T1 | Displays the distance driven and the
|-------------------------|-----------------|------| operating times for the machine, the
| 6 , 7 3 h M a c h | | T2 | tractor and the operator for the
current
|-------------------------|-----------------|------| order.
| 7 , 5 5 h T r a c | | T3 |
|-------------------------|-----------------|------| Right:
| 9 , 8 6 h O p e r | N e x t | T4 |---> Op Press the T4 key to go back to the
+-------------------------\-----------------\ | operation data
\-----------------\-----+
+---------+
| ha/h |
+----------------------------------------| ----- |
| | 1/min |
v /-----------------/-----+ +---------+
+-------------------------/-----------------/ | Left:
| 3 , 3 2 h a / h | | T1 | Displays the current and average area
|-------------------------|-----------------|------| efficiency.Displays the power take-
off
| 3 , 0 8 h a / h | | T2 | shaft rotation (PTO rpm).
|-------------------------|-----------------|------|
| P T O : | | T3 |
|-------------------------|-----------------|------| Right:
| 5 2 0 1 / m i n | N e x t | T4 |---> Op Press the T4 key to go back to the
+-------------------------\-----------------\ | operation data.
\-----------------\-----+
