Warning Labels
The following chart details the warning signs and labels and their locations on the machine.
They are designed to assist and remind the operator to exercise caution when approaching the
machine and the working area.
Operators should read carefully and take due note of the warnings and instructions for safe
operation before operating the machine.
In addition to the warning labels on the machine the workplace should also be adequately
signed for the wearing of personal protective equipment, e g eye and hearing protection, and
the zones where these precautions are necessary clearly marked.
HAZARD NOTICE TABLE
Hazard Requirement Location
Hearing Protection Mandatory On the Machine Head
Eye Protection Mandatory On the Machine Head
Electrical Power Warning On the Inverter Box
Electrical Power Warning On the Controller Box
Electrical Power Warning On the Power Box
Cutting Hazard Warning On the Machine Spindle
On Knife head attachments
Emergency Stops Mandatory On both ends of the Gantry
Air Pressure Warning On the Machine Frame
Striking Warning On the X axis Bearing
Cover
Striking Warning On the Tool Changer Cover
Striking Warning On the Machine Head
Pinch Point Mandatory Near clamp activation
switch
Cutting Hazard Mandatory On the Spindle pickup
housing
On Knife head attachments
Position or appearance of labels may very in accordance with devices that form
part of the work cell. Always observe all safety labels and advisory notices.
Note. The warning labels must not be removed from the machine.
