User Manual
5. Interface Setting
(1) Press the
arrow keys to select the baud rate, and press the
/
arrow keys to set the baud rate of the RS232 serial interface. The optional
values for the baud rate are: 2400, 4800, 9600, 19200, 38400, 57600,
115200, and the factory default setting is 115200. Make sure the
instrument's baud rate setting matches the baud rate setting of the
computer you are using.
(2) Press the
arrow keys to select the check digit and press the
/
arrow keys to toggle None, Odd, Even.
(3) Press the
arrow keys to select the stop bit, and press the
/
arrow
keys to toggle 1 or 2.
Note: The data bits submenu cannot be set, and the data bits are fixed at 8
bits.
6. System Information
6.1.1 Review System Information
Press the System softkey and turn the rotary control to select the [SYSTEM]
menu. The screen shows the model number, version number, and serial
number of the machine.
6.1.2 Restore Factory Settings
Press the System softkey and turn the rotary control to select the [SYSTEM]
menu. Press
arrow keys to select the Factory Reset submenu. Press OK to
restore the factory default settings. See the factory setting detail table below
Output
Voltage Current
5 V 2 A
Limit
Voltage Current
MAXOUT MAXOUT
