User Manual
arrow keys or turn the rotary control to set the display mode to Number or
Curve.
In system main interface, you can also press the OK key or press the rotary
control to toggle between Number and Curve display mode.
Number
Press the System softkey and turn the rotary control to select the [Utility]
menu. Press the
arrow keys to choose Display submenu. Press the
/
arrow keys or turn the rotary control to set the display mode to Number.
In system main interface, you can also press the OK key or press the rotary
control to select the Number display mode. When the power supply is
powered on, the default display mode is Number.
Curve
Press the System softkey and turn the rotary control to select the [Utility]
menu. Press the
arrow keys to choose Display submenu. Press the
/
arrow keys or turn the rotary control to set the display mode to Curve.
In system main interface, you can also press the OK key or press the rotary
control to select the Curve display mode.
4.1.5 Curve Type
You can set the type of the displayed curve to voltage curve or current curve.
1) Voltage Curve
Two methods to set the curve type to voltage curve.
1st Method:
