Measuring System
Automatic Measurement
Press and the F1 key to realize automatic measurement. There are 7
types of measurement, and up to 6 types of measurement can be displayed at
the bottom left of the screen. Auto range includes frequency, period, amplitude,
maximum, minimum, peak-to-peak value, and average value.
The description of the automatic measurement Function Menu is as follows:
Automatic
measurement
Turn automatic measurement on
or off.
Source
Set the source.
Add
Delete
Period (T)□
Amplitude (Va)□
Maximum (Ma)□
Minimum (Mi)□
Peak to Peak
value (Vpp)□
Average value
Add or delete the selected
measurement type (displayed in
the lower left corner, up to 6
types).
Note: The unselected state is □;
The selected state is ■.
Cursor Measurement
Press and the F2 key to realize cursor measurement.
The description of Cursor Measurement Menu is as follows:
Setting
Type
CH2
Time
Select to display the CH1 cursor and menu.
Select to display the CH2 cursor and menu.
Select to display the time measurement cursor
and menu.
Turn off the cursor measurement.
To Next Page
